porous sintered metal filter cartridge
- stainless steel
- 20um
- OD30*2.5*210MM
- porous sintered metal filter cartridge
- Product description: sintered porous metal cartridge filters ,High performance porous metal strainer cartridge for oil filter for hydraulic oil filtration ,High performance porous metal strainer cartridge for oil filter f
Product introduction
sintering Metal Powder Filter Cartridge
Brife Inreoduction
It is made of stainless steel powders by being molded and sintered in a high temperature. Unique technology and strict production process (including distribution, molding and sintering of powder particles) determine its advantages of high strength, excellent heat and corrosion resistance, uniform aperture distribution, good permeability, repeated cleaning and reuse, weldable and machinable property. Porous sintered metal filter that has a wide range of filter rating is produced by adjusting particle sizes and technical conditions. As a result of numerous advantages, stainless steel powder filter is widely used in filtration and separation of chemical, pharmaceutical, beverage, food, metallurgy, petroleum and environmental industries, such as A) rough filtration and fine filtration of medical solution, oil, beverage, mineral water. B) dedusting, degerming and oil mist removal of various gas and steam. C) noise reduction, flame resistance and gas buffer.
Features and Benefits
1. All-stainless steel construction
2. Controlled and fixed pore size
3. PH grade for clean steam
4. High pressure and corrosion resistant
5. Withstands high reverse-flows
6. High-temperature capabilities
7. Repeatedly cleanable
8. No unloading or shedding
9. Absolute rated for reliable performance
10. ISO 9000 Certified Quality System
Application:
separation and purification of solid-liquid, gas-liquid and gas-solid in the petrifaction, hydraulic manufacturing and medical apparatus and instruments of basic industries.
Technique parameters
Filtering Level |
Filtration Precision um |
Maximum Hole Diameter um |
Permeability Coefficient 10-12m2 |
Permeability m3/h.m2.kpa |
Thickness mm |
Compression Strength Mpa/cm2 |
Bubbling Pressure Kpa |
S9 |
0.2 |
2.5 |
|
1 |
0.6-10 |
3.0 |
|
S8 |
0.5 |
4 |
|
3 |
0.6-10 |
3.0 |
|
S7 |
1.5 |
6 |
|
5 |
0.6-10 |
3.0 |
|
S6 |
2.5 |
10 |
0.09 |
10 |
0.6-10 |
3.0 |
9.16 |
S5 |
5 |
15 |
0.23 |
40 |
0.6-10 |
3.0 |
6.1 |
8 |
20 |
0.91 |
80 |
0.6-10 |
3.0 |
4.6 |
|
S4 |
10 |
30 |
1.81 |
160 |
0.6-10 |
3.0 |
2.6 |
S3 |
28 |
60 |
3.82 |
350 |
0.6-10 |
3.0 |
1.8 |
35 |
80 |
7.29 |
500 |
0.6-10 |
3.0 |
1.4 |
|
S2 |
40 |
100 |
9.43 |
700 |
0.6-10 |
3.0 |
1.1 |
S1 |
65 |
160 |
15.1 |
1000 |
0.6-10 |
3.0 |
0.66 |
