titanium porous plate 160 * 160 * 1.5mm
- size :160 * 160 * 1.5mm
- tolerance :+/_0.05MM
- FILTERING PRECISION: 5um
- titanium porous plate
- Product description: microns porous metal engineered assemblies, microns sintering porous metal filter material, sintered porous titanium cartridge filter tube, sintering titanium filter plate, microns sinter titanium dis
Product introduction
1.MATERIAL: 99.4% MIN. TITANIUM POWDER
2.TECHNICAL DATA:
1) FILTERING PRECISION: 5um
2) POROSITY : 28-50%
3) WORKING TEMPERATURE MAX.: 300 ℃ (WET)
4) size :1.5*160*160MM
5) MAX. DIFFERENCE OF WORKING COMPRESSIVE STRENGTH: 1.0MPa
3. ALLOWABLE WORKING ENVIRONMENT: NITRIC ACID, FLUORIDE SALTS, LACTIC ACID, LIQUID CHLORINE, SEA WATER, IN THE AIR.
4.FORMING SHAPES:
Filtering Level |
Filtration Precision um |
Maximum Hole Diameter um |
Permeability Coefficient 10-12m2 |
Permeability m3/h.m2.kpa |
Thickness mm |
Compression Strength Mpa/cm2 |
T9 |
0.2 |
2.5 |
|
1.5 |
0.6-2.0 |
3.0 |
T8 |
0.5 |
4 |
|
3 |
0.6-2.0 |
3.0 |
T7 |
1 |
6 |
|
5 |
0.6-2.0 |
3.0 |
T6 |
2 |
10 |
|
15 |
0.6-2.0 |
3.0 |
T5 |
5 |
15 |
0.04 |
40 |
0.6-2.0 |
2.5 |
T4 |
10 |
30 |
0.15 |
120 |
0.6-2.0 |
2.5 |
T3 |
20 |
60 |
1.01 |
250 |
0.6-2.0 |
2.5 |
T2 |
30 |
100 |
2.01 |
500 |
0.6-2.0 |
2.5 |
T1 |
50 |
160 |
3.02 |
800 |
0.6-2.0 |
2.5 |
