Microporous metal filter element
- Microporous metal filter element
- Filtering precision:28%-50%
- Filtering precision:0.2-50um
- Titanium powder sintered microporous materials
- Product description: Titanium powder sintered/Metal Filter Cartridge ,GR2 Porous titanium sinter ,sintered metal powder sintering ,titanium powder sintered filter plate sheet ,Microns SS 316L porous filter stainless steel
Product introduction
Titanium powder sintered microporous materials(Gr1 Gr2)
A. Titanium microporous filter core and components
B. Titanium microporous filter plate surface coated with precious metals like tantalum(Ta), platinum(Pt), used for hydrogen cell, Ozone generator anode plate and so on.
A. Stainless steel power sintered microporous filter core and components
B. Stainless steel microporous filter plate, welded reelpipe
Features:
Average pore size: 10 to 20 microns
Porosity: above 35% to 40%
Filtering precision:0.2-50um
Maximum size: 1000mm max. Long; 270mm max.Width; 0.5-2mm max.Thickness
Powder compacting process: For the sheet and round forms, it is hot rolled; for tube, it is Isostatic pressing
Filtering level
Filtering precision
Um
Maximum Aperture
Um
Permeability
m3/h.m2.kpa
Thickness
mm
Compressivestrength
Mpa/cm2
T9
0.2
2.5
1.5
3
3.0
T8
0.5
4
3
3
3.0
T7
1
6
5
3
3.0
T6
2
10
15
3
3.0
T5
5
15
40
3
2.5
T4
10
30
120
3
2.5
T3
20
60
250
3
2.5
T2
30
100
500
3
2.5
T1
50
160
800
3
2.5
Product craft
sintered titanium plates are produced by processing the anomalous powder of pure or alloy titanium. They are formed through static pressure, mould pressing and extrusion.
Application
They are mainly applied to the separation and purification of solid-liquid, gas-liquid and gas-solid in the petrifaction, hydraulic manufacturing and medical apparatus and instruments of basic industries. separation and purification of solid-liquid, gas-liquid and gas-solid in the petrifaction, hydraulic manufacturing and medical apparatus and instruments of basic industries.
Feature:
1.Working Temperature:-200—1000°C
2.Corrosion Resistance
3.High Filtering Efficiency
4.Metallic capacities, such as noise reduction,hot resistance,heat conduction,high strength and etc
5.Easy to welding and long working life
Filter Shape:
Could be cartridge filters,disc filters ,cup filters,cap filters,filter palte and etc
