Sintered titanium powder filter cartridge - 副本
- Product ID:105554
- weight:2kg
- FILTERING PRECISION: 0.45μm - 120μm
- COMPRESSIVE STRENGTH: 0.5-1.5MPa
- Product description: Sintered titanium powder filter cartridge,Porous sintering stainless steel mesh filters ,Sintered titanium powder filter cartridge,Titanium Sintering micro-porous filter,Titanium Sintered Filter for W
Product introduction
Sintered titanium powder filter cartridge
Details
Mechanical strength
Metal structure and sintered at high temperature
High temperature and pressure resistant
Cartridges can work under
extreme
high
temperature and pressure conditions.
Wide chemical compatibility
Cartridges can resist to strong
acid, alkaline
and
Ozone Oxidation.
Long life
Cartridges can be backwashable and
cleaned
by chemical
solvent, hot water,steam
Materials
Filter Media:Titanium powder
Sintered
SUS316
powder Sintered
SUS316 mesh pleated
Cartridge Dimensions (Nominal)
Outer Diameter:
60mm/80mm
Length:
10"-250mm
Length:
20"- 500mm 30"-750 mm
40"- 1000mm
*(Length is based on Cut
ends)
Nominal Micron
Filtering level
|
Filtering precision (μm) |
Maximum Aperture (μm) |
Permeability (m3/h.m2.kpa) |
Thickness (mm) |
Compressive strength (Mpa/cm2) |
T9 |
0.2 |
2.5 |
1.5 |
3 |
3.0 |
T8 |
0.5 |
4 |
3 |
3 |
3.0 |
T7 |
1 |
6 |
5 |
3 |
3.0 |
T6 |
2 |
10 |
15 |
3 |
3.0 |
T5 |
5 |
15 |
40 |
3 |
2.5 |
T4 |
10 |
30 |
120 |
3 |
2.5 |
T3 |
20 |
60 |
250 |
3 |
2.5 |
T2 |
30 |
100 |
500 |
3 |
2.5 |
T1 |
50 |
160 |
800 |
3 |
2.5 |
Typical Applications
Suitable for the extreme operating
enviroments, steam filtration.
Pharmaceuticals:Prefiltraion and
decarbonate filtration.
Food & Beverages:Viscous liquid
with high temperature.
Fine Chemicals: Strong Acid and
Alkaline filtration.
Water:Filtrate the O-zone containing
water.
Cartridge Cleaning Methods
* Pharmaceutical, Food &
Beverage industries:
Hot water flush; Steam clean; Water
Backwash
Brush
clean; Compress air blow.
* Chemical Industry:
Chemical Solvent clean; Ultrasonic
cleaning
High
pressure water spray rinsing; Acid dipping
