Stainless Steel Sintered Powder tubes - 副本 - 副本
- Micron Rate:0.2um-100um
- Filtering precision:28%-50%
- SS Microporous filter
- COMPRESSIVE STRENGTH: 0.5-1.5MPa
- Product description: Stainless Steel Sintered Powder tubes,metal powder cartridges, porous stainless steel filters,Sintered Metal Powder Filter Element (porous metal filter),sintered titanium powder filters (tubes),sinter
Product introduction
Sintered Metal Powder Filters
Sintered Metal Powder Filter Element (porous metal filter) are ideal choice for process filtration applications where high strength and excellent corrosion and temperature resistance are required.
Manufactured from isostatically compacted and sintered metal powders ensure excellent powder uniformity and strength for superior filtration performance and long life.
Features
● High strength and dimensional stability
● Continuous operating temperature range of -50° C to 600° C
● Stainless steel construction
● Corrosion/abrasion resistant
● Custom configurations, including layers of perforated plate, fiber metal felts and photo-etched foil
● Precise pore size distributions and fluid flow permeability
● Easily cleaned/back-flushed
●No media migration, no second pollution to media and meet GMP requirements
Main Data
Micron Rate |
Porosity |
Penetrability |
Pressure Resistance |
Maximum Working Temp. |
Max. Differential Pressure |
0.2um-100um |
28-50% |
0.02-20L/cm2minPa |
0.8Mpa |
500-600℃ (Wet) |
0.6Mpa |
Specifications
Diameter |
Ф22mm Ф30mm Ф50mm Ф60mm Ф80mm Ф100mm Ф120mm |
Length |
L125 L250 L300 L500 L600 L750 L1000 (Can tailor made acc. to request) |
Thickness |
Above 1 mm (others could be tailor made acc. to request) |
Micron Rating |
0.45 um 1 um 3 um 5 um 10 um 20 um 30 um 50 um 80 um 100 um 120 um |
Applications
●Filtration in Chemical Processing: Removal of precious metal catalyst from an organic intermediates stream
● Gases: Filtration of fine particles in nitrogen stream
● Polymers: Removal of gels and black specks in polyethylene, polypropylene, and fluorinated polymers
● Power Generation Plants: Remove iron oxide and other impurities from condensate water
● Food/Beverage: Removal of iron oxides in steam service; removal of pulp from fruit juices
● Oil field injection water filtration: guard filtration of seawater desalination reverse osmosis
● Water: Pure water production; pre-filter of RO membrane; After- filter of sterilizing unit of beverage; high-temp. circulating water filtration in electric power plant; sewage treatment, and so on
● Ozone filtration and after ozone sterilization
CMI CODE TABLE: For example: CMI SPSS045 20 N
Brand Name |
Product Name (SS sintered) |
Filtration Rating |
Length |
Connection |
Gasket |
Fitow |
SPSS |
045(0.45micron) 1 (1 micron) 10 (10micron) . . . 100 (100micron) |
5 (5 Inch ) 10 (10Inch) 20(20 Inch) 30 (30 Inch) 40(40 Inch) |
2-226 flat 4-226 with fin 6-222 with fin 7-DOE 9-Screws N-nonstandard |
B-Buna V-Viton E-EPDM S-Silicon |
