New Energy microporous titanium coating ruthenium, platinum-coated, coated iridium electrode plates - 副本
- thickness0.65mm
- ruthenium, platinum-coated, coated iridium electrode plates
- FILTERING PRECISION: 50um
- COMPRESSIVE STRENGTH: 0.5-1.5MPa
- Product description: New Energy microporous titanium coating ruthenium, platinum-coated, coated iridium electrode plates : SUS 316L filter disc, sintering SS filter cartridge,powder sintered stainless steel filter tube, s
Product introduction
New Energy microporous titanium coating ruthenium, platinum-coated, coated iridium electrode plates
Porous Titanium sintered plates
1.Thickn
ess:0.6-10mm
2.Max Length:1000mm
3.Max width:270mm
4.Filtering level:T1-T9
5.Filtering precision:0.2-50um
General Description
Material |
Gr1 Titanium as substrate, Platinum as coating
|
Technology |
Sand blasting,acid washing and Brush coating
|
Coating Thickness |
Platinum as coating 0.5-4 micron |
|
|
Dimension & Shape |
Different dimension and shape is available |
Working Principle |
Water electrolysis
|
The reaction on the anode and cathode of water electrolysis
|
|
H2O=H2↑+1/2O2 |
|
Cathode:2H2O+2e=H2↑+2OH- |
|
Anode:2OH-—2e=1/2O2+H2O |
|
Working Parameter |
1) Current density max 2000A/M2 |
2) Temperature≤60°C |
|
Features |
1) High anti-corrosion property |
2) Lasting working life |
|
3) Keep the operating voltage stably |
|
4) High current efficiency |
|
5) High catalytic property |
we supply all kinds of sintered filter elements as your request with excellent quality.such as Sintered titanium and its alloy filter elements,Sintered Nickel its alloy filter elements,Sintered Stainless steel filter elements. according to the customer's requirements provide tubular, plate, sheet, dishes, bar, cone and strip.
Product craft
sintered titanium plates are produced by processing the anomalous powder of pure or alloy titanium. They are formed through static pressure, mould pressing and extrusion.
Application
They are mainly applied to the separation and purification of solid-liquid, gas-liquid and gas-solid in the petrifaction, hydraulic manufacturing and medical apparatus and instruments of basic industries.
Porous Titanium Sinter Technique Parameters
Application Temperature ≤300°C
Filtering Level |
Filtration Precision um |
Maximum Hole Diameter um |
Permeability Coefficient 10-12m2 |
Permeability m3/h.m2.kpa |
Thickness mm |
Compression Strength Mpa/cm2 |
T9 |
0.2 |
2.5 |
|
1.5 |
0.6-2.0 |
3.0 |
T8 |
0.5 |
4 |
|
3 |
0.6-2.0 |
3.0 |
T7 |
1 |
6 |
|
5 |
0.6-2.0 |
3.0 |
T6 |
2 |
10 |
|
15 |
0.6-2.0 |
3.0 |
T5 |
5 |
15 |
0.04 |
40 |
0.6-2.0 |
2.5 |
T4 |
10 |
30 |
0.15 |
120 |
0.6-2.0 |
2.5 |
T3 |
20 |
60 |
1.01 |
250 |
0.6-2.0 |
2.5 |
T2 |
30 |
100 |
2.01 |
500 |
0.6-2.0 |
2.5 |
T1 |
50 |
160 |
3.02 |
800 |
0.6-2.0 |
2.5 |
